The short version of how to cut polycarbonate sheet: use the finest-toothed blade you have, keep the feed rate steady, support the sheet along the whole cut, and leave the protective film on both faces while you work. Polycarbonate is far more forgiving than acrylic. It will not chip and it will not craze, so most people get a usable cut on their first go.

What ruins it is heat. Polycarbonate is a thermoplastic with a habit of softening, gumming onto the blade and then re-welding itself behind the cut. You end up with a rough, cloudy edge and a blade packed with melted plastic. Every rule below exists to keep the heat down.

Which tool to use, by thickness

The tool follows the thickness, not the other way around. This is the part most guides skip.

One warning that matters. Scoring and snapping is an acrylic technique, not a polycarbonate one. Acrylic is brittle and breaks cleanly along a scored line. Polycarbonate is ductile, so it bends, stretches and tears rather than snapping. On anything above about 2mm it will not work at all, and on thin sheet it leaves a stretched, whitened edge.

Blade selection and feed rate

This is where the cut is won or lost.

Tooth count. Go fine. On a circular saw, a 60 to 80 tooth blade on a 184mm disc is the right neighbourhood. A triple-chip grind is better than a standard alternate-top-bevel, because it shears the material rather than gouging it. On a jigsaw, use a fine metal-cutting blade, not a wood blade.

Speed. Slower than you think on the tool, steadier than you think on the feed. High blade speed plus a slow feed is the combination that melts polycarbonate, because the blade sits in one place generating heat without clearing material. If your jigsaw has a speed dial, wind it down.

Feed rate. Consistent and moderate. Pausing mid-cut is how you get a melted notch you cannot sand out. If you need to stop, back the blade out first.

Support. Clamp or support the sheet along the full length of the cut, close to the line. Unsupported polycarbonate flexes, the kerf closes on the blade, and the friction does the rest.

Blade condition. A blunt blade is a heat source. If the blade is worn enough that you are pushing, you are melting.

Leave the film on, and keep track of the UV side

Two habits that cost nothing and save the sheet.

Leave the protective film on both faces. Right through cutting, drilling, handling and fitting. Peel it only once the panel is in place. The film is the reason a new sheet arrives unscratched, and polycarbonate scratches more easily than acrylic does. Cutting through the film is fine and it also reduces the chance of the shoe of a saw marking the surface.

Know which face carries the UV layer. Most exterior-grade polycarbonate has a co-extruded UV-protective layer on one side only, and that side has to face the sun. It is normally marked on the printed film, which is another reason not to strip the film early. Fit a sheet upside down and it will yellow and go brittle in a few Perth summers, which defeats the entire point of choosing polycarbonate.

If you have already lost track of which face is which, do not guess. Ask whoever supplied the sheet.

Cutting twin wall polycarbonate sheet

Twin wall polycarbonate sheet is a different job to solid sheet, and the flutes are the reason.

Cut it with a fine-tooth blade the same way, but cut along the flutes wherever the design allows, because a cut across them opens every channel. Support it well; the hollow structure flexes far more than solid sheet of the same thickness.

The part people forget is what happens after the cut. Every open flute is now a channel that will collect dust, insects and condensation, and once it is in there it does not come out. The open ends need sealing: breather tape on the bottom edge so moisture can escape, solid tape on the top edge, then the appropriate profile over both. A sheet that goes up with unsealed flutes looks fine for a season and grubby forever after.

Blow the swarf out of the flutes before you seal them. A cut that traps its own offcuts is a cut you will be looking at for years.

Drilling polycarbonate without cracking it

Good news first: polycarbonate is much more forgiving to drill than acrylic. Acrylic needs a modified bit with the rake ground off, or it grabs and spiders the sheet. Polycarbonate will take a standard sharp HSS bit.

The rules that still apply:

1. Slow speed, steady pressure. Same heat logic as cutting. A fast bit in thin sheet melts a ring rather than cutting a hole.
2. Back the sheet with scrap timber. It stops the bit snatching as it breaks through and keeps the exit side clean.
3. Stay away from the edge. Keep hole centres at least twice the hole diameter from any edge.
4. Oversize the hole. This is the one people miss. Polycarbonate expands and contracts noticeably with temperature, so a fixing hole should be larger than the fastener, typically by a few millimetres on a long panel, and the fastener should not be done up tight. A panel screwed down hard has nowhere to go on a hot day.

That last point causes more field failures than bad drilling does.
